Parking modules, perpendicular + angled + accessible + loading

A single-level parking modules, perpendicular + angled + accessible + loading template with a 46 × 32 m footprint and 3.5 m overall height. The model includes 4 variants, 8 perpendicular bays, 4 angled bays, 2 accessible bays, 1 loading bays, 5 vehicles.

Four nominal modules on one level site. Perpendicular bays 2.6 × 5.2 m with 6.4 m two-way aisle; angled bays 2.6 × 5.2 m at 45 degrees, 3.82 m centre spacing and 5.4 m aisle.

The template ships with 5 saved scenes: a street-level approach, 3 interior views and an aerial three-quarter, plus a site pad with neighbouring context massing, a north point and a 1.7 m scale figure, so you can render or edit from any of them straight away. Dimensions are nominal metric starting points informed by published precedents; it is an original design, not a survey.
