Core bundle, stair, lift and ramp
A 3-level core bundle, stair, lift and ramp template with a 19 × 15 m footprint and 10.2 m overall height. The model includes 2 stairs, 2 lifts, 6 wcs, 3 accessible wcs, 3 risers, 3 storeys.
The source candidate is named Compliant core bundle; this model deliberately claims no compliance. Occupancy, fire separation, travel distances, accessibility, sanitary provision and engineering require project-specific assessment.
The template ships with 5 saved scenes: a street-level approach, 3 interior views and an aerial three-quarter, plus a site pad with neighbouring context massing, a north point and a 1.7 m scale figure, so you can render or edit from any of them straight away. Dimensions are nominal metric starting points informed by published precedents; it is an original design, not a survey.
Size | 19 × 15 m, 3 levels |
Program | 2 stairs, 2 lifts, 6 wcs, 3 accessible wcs, 3 risers, 3 storeys |
Scenes | 5 saved views: street, 3 model views, aerial |
