Data centre hall, nominal 5 MW IT load

A 2-level data centre hall, nominal 5 mw it load template with a 90 × 100 m footprint and 9 m overall height. The model includes 500 racks, 5 nominal itload mw, 5 containment aisles, 6 generators, 6 cooling skids.

Six generator enclosures and six cooling skids are representative plant, not certified redundancy or MEP sizing.

The template ships with 5 saved scenes: a street-level approach, 3 interior views and an aerial three-quarter, plus a site pad with neighbouring context massing, a north point and a 1.7 m scale figure, so you can render or edit from any of them straight away. Dimensions are nominal metric starting points informed by published precedents; it is an original design, not a survey.
