Five-level car park, 400 marked bays + external ramps

A 5-level five-level car park, 400 marked bays + external ramps template with a 78 × 65 m footprint and 17 m overall height. The model includes 400 parking bays, 5 levels, 80 bays per level, 4 vehicle ramps, 2 stair cores, 1 lifts.

Five flat decks each contain exactly 80 individual 2.6 × 5.2 m bays. Four two-way 7 m wide external ramps each rise 3.2 m over a 30 m central run, with level end turning platforms and deck connectors. No traffic, swept-path, structural or access compliance is certified.

The template ships with 5 saved scenes: a street-level approach, 3 interior views and an aerial three-quarter, plus a site pad with neighbouring context massing, a north point and a 1.7 m scale figure, so you can render or edit from any of them straight away. Dimensions are nominal metric starting points informed by published precedents; it is an original design, not a survey.
