Kimbell Art Museum

Kimbell Art Museum in Fort Worth, United States, by Louis I. Kahn, rebuilt as an approximate visual BIM model from 6 published architectural references. The building measures 52 × 98 m on plan and 6.3 m tall, across 2 named levels: Kahn gallery floor — nominal datum, Cycloid vaults and skylights.

Modelled detail includes sixteen cycloid concrete vaults in6/4/6 groups, continuous central roof light slots and suspended wing-shaped daylight reflectors.

The template ships with 6 saved scenes — a street-level approach, 4 viewpoints from the building's own observation set, and an aerial three-quarter — and carries the real site at 3333 Camp Bowie Blvd, Fort Worth, TX 76107, USA, so map context and sun angles line up when you open it. It is an approximate visual reconstruction for design and presentation use, not a measured survey, certified BIM, engineering model or construction document.
