Utility enclosures, pump-house and substation variants

A single-level utility enclosures, pump-house and substation variants template with a 22 × 14 m footprint and 4.4 m overall height. The model includes 2 variants, 2 pump envelopes, 1 transformer envelopes, 3 switchgear envelopes.

Two distinct utility enclosures are original nominal spatial designs. Equipment is represented by exterior mass and maintenance zones. No pump sizing, hydraulic pressure, electrical wiring, energisation, protection or safe working procedure is supplied.

The template ships with 4 saved scenes: a street-level approach, 2 interior views and an aerial three-quarter, plus a site pad with neighbouring context massing, a north point and a 1.7 m scale figure, so you can render or edit from any of them straight away. Dimensions are nominal metric starting points informed by published precedents; it is an original design, not a survey.
